Hyundai
Hyundai DP086CCP
DP086 Series
Hyundai DP086CCP 7.5L 6-cylinder diesel engine for generator sets. EPA Tier 4 Final certified.
Overhaul & repair parts- Supporting documents
- 4 documents · 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 280 kVA
- Electrical Output
- 224 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 225.6 | 203 | 253.8 |
| Standby Power | 248.9 | 224 | 280 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 258.9 | 233 | 291.3 |
| Standby Power | 285.6 | 257 | 321.3 |
Ask about Hyundai DP086CCP
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai DP086CCP overhaul & repair parts
Already running a Hyundai DP086CCP? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP086CCP and your selected categories included. Attach your photos there.
Hyundai DP086CCP generator set context
The Hyundai DP086CCP is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 280 kVA / 224 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CCP |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CCP?
The Hyundai DP086CCP is rated at 280 kVA standby / 254 kVA prime at 50 Hz (1,500 rpm); and 321 kVA standby / 291 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CCP run at 50 Hz or 60 Hz?
The Hyundai DP086CCP is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CCP use?
The Hyundai DP086CCP is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CCP?
The Hyundai DP086CCP is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
What emissions information is listed for the DP086CCP?
This record lists U.S. EPA Final Tier 4 for the Hyundai DP086CCP. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Hyundai DP086CCP?
The Hyundai DP086CCP is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP086CCP?
This page links reference documents for the Hyundai DP086CCP. Check each document's title, model coverage, revision and rating conditions before using it for selection.
