Hyundai
Hyundai DP086CDP
DP086 Series
Hyundai DP086CDP 7.5L 6-cylinder diesel engine for generator sets. EPA Tier 4 Final certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP086CDP and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 309 kVA
- Electrical Output
- 247 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 248.9 | 224 | 280 |
| Standby Power | 274.4 | 247 | 308.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 278.9 | 251 | 313.8 |
| Standby Power | 308.9 | 278 | 347.5 |
Hyundai DP086CDP generator set context
The Hyundai DP086CDP is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 309 kVA / 247 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CDP |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CDP?
The Hyundai DP086CDP is rated at 309 kVA standby / 280 kVA prime at 50 Hz (1,500 rpm); and 348 kVA standby / 314 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CDP run at 50 Hz or 60 Hz?
The Hyundai DP086CDP is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CDP use?
The Hyundai DP086CDP is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CDP?
The Hyundai DP086CDP is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
What emissions standard does the DP086CDP meet?
The Hyundai DP086CDP is certified to U.S. EPA Final Tier 4 emissions standards.
Is the Hyundai DP086CDP still in production?
Yes — the Hyundai DP086CDP is a current production model.
Is a datasheet available for the DP086CDP?
Yes — an official Hyundai datasheet for the Hyundai DP086CDP can be downloaded from this page.
